55 Inch LCD Panel

Product Details

UHD ips 55 inch lcd panel HV550QUB-N5K / HV550QUB-N5L

MOQ: 20 pieces,support mixed

Product Specifications

Panel Brand	BOE	Model	HV550QUB-N5K/HV550QUB-N5L
Diagonal Size	55″	Frequency	60Hz
Pixel Format	3840(RGB)¡Á2160, UHD, 80PPI	Signal Interface	V-by-One 8 lane , 51 pins Connector
Active Area(mm)	1209.6(W)¡Á680.4(H) mm	Input Voltage	12.0V (Typ.)
Outline Size	1219.6(W)¡Á691.9(H) ¡Á1.32(D) mm	Panel Type	a-Si TFT-LCD , CELL
Display Colors	1.07B 74% NTSC	Bezel Opening	–
Driver IC	COF Built-in 12 source chips	Surface	Antiglare (Haze 1%), Hard coating (2H)
Panel Weight	2.58Kgs (Typ.)	Contrast Ratio	1200:1 (Typ.) (TM)
White Coordinate	Wx:0.287; Wy:0.306	Transmissivity	4.8% (Typ.)(with Polarizer)
Color Temperature	8624K	Quantity	15 pcs / box
Display Colors	1.07B (8-bit + Hi-FRC)	Box Size	1400¡Á935¡Á118 mm (L¡ÁW¡ÁH)

Guarantee

We have 100% quality guarantee to customers. We will be responsible for any quality problem.

Product Packing

Totally 10pcs panels and 11Pcs EPE Pad per box, then use standard wooden pallet.

FAQ

Q: What’s your products?

A: 55 inch lcd panel and other BOE/ SAMSUNG/ LG/ CSOT/ AUO/ PANDA/ INNOLUX/ CHOT/ HKC Lcd panel, tv shell, tv main board, tv tcon, adapter, tv led strips, tv speakers, lcd cof, cable ffc, tv stand, tv lightbar, etc.

Q: How can I place an order?

A: You can contact any of our sales person for an order. Please provide the details of your requirements as clear as possible. So we can send you the offer at the first time. For designing or further discussion, it is better to contact us with wechat or WhatsApp or other instant ways, in case of any delays.

Q: What is your terms of delivery?

A: We accept EXW, FOB, CFR, CIF, etc. You can choose the one which is the most convenient or cost effective for you.

Q: What is the payment way?

A: 1)TT or Wester Union for the trial order

2) ODM, OEM order, 30% for deposit, 70% against the copy B/L.

We are factory, we can guarantee our price is first-hand, High quality and competitive price.
