Panel Samsung 32

Product Details

Panel samsung 32 LSC320AN10/ LSC320AN09-H03/ 16Y_GH11MB7S4LV0.2

RGB TV SCREEN is a company specialized in export TV LCD display products.The main dimensions: 23.6 “,32″ ,40″ ,43″,48″,49″,54.6″,58″ ,65″,75″,86″,98” led lcd tv panel.

Cooperation Main brand: panel Samsung, lg, boe, auo, csot, etc.

Product Description

MOQ: 20 pieces,support mixed

Panel Brand	SAMSUNG	Model	LSC320AN10
Diagonal Size	32.0″	Frequency	60Hz
Pixel Format	1366¡Á768(RGB), WXGA, 49PPI	Signal Interface	LVDS (1 ch, 8-bit), 30 pins Connector
Active Area (mm)	697.685(W)¡Á392.256(H) mm	Input Voltage	12.0V (Typ.)
Outline Size	713(W)¡Á410.5(H) ¡Á1.3(D) mm	Panel Type	a-Si TFT-LCD , CELL
Brightness	0 cd/m?	Pixel Format	RGB Horizontal Stripe
Glass Depth	0.40+0.50 mm	Surface	Antiglare
Display Colors	16.7M 68% NTSC	Contrast Ratio	5000:1 (Typ.) (TM)
Driver IC	COF Built-in 1 source chips	Display Mode	PVA, Normally Black, Transmissive
Panel Weight	800g (Typ.)	Response Time	20 (Typ.)(G to G)
Chromaticity	Wx:0.297; Wy:0.361	Color Numbers	16.7M (8-bit)
Color Temperature	6997K	Uniformity	–
NTSC Ratio	69%	sRGB	84% coverage
Adobe RGB	71% coverage	DCI-P3	70% coverage
Rec.2020	51% coverage	Remarks	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

Product Process

Non-dust workshop, test one-by-one.

Product Marking

Sticker model: LSC320AN10/ LSC320AN09-H03

PCB model: 16Y_GH11MB7S4LV0.2

a. Power GND pins should be connected to the LCD’s metal chassis.

b. All power input pins should be connected together.

c. All NC pins should be separated from other signal or power.

LSC320AN10 Packing

FAQ

Q: Are you trading company or manufacturer?

A: We are professional LCD OPEN CELL trading company and also professional tv manufacture. specialized in led tv and tv parts products. And we trade our products with our clients directly.

We are LCD open cell supplier from 18.5inch to 86inch and have 10years experience in this field. Please add me WECHAT or WHATSAPP: +8618684827762, then I can answer u ASAP.

Q: Can you do OEM and ODM?

A: Yes, LED TV LCD TV OEM and ODM are both acceptable. The material, color, style can customize, the basic quantity we will advise after we discuss.

Q: What’s your MOQ?

A: TV LCD OPEN CELL divided different brand. RGB have quality channels for BOE/ SAMSUNG/ LG/ AUO/ CSOT panel brands. If we have the products in stock, it will be no MOQ. If we need to find, we can discuss the MOQ according to customer’s exact situation.

Q: How long is your delivery time?

A: The general delivery time is 3-7 days after receiving your order confirmation. Anther, if we have the goods in stock, it will only take 1-2 days.

Q: What is your term of payment?

A: 30% down payment before PI or producing and 70% balance payment before shipping.
